6.2.10 FlexCurves
This screen can be accessed at Actual> Status > Flex Curves, and it includes the internal flex curves status.
If the LED associated with the FlexCurve status is lit up, this indicates that the user curve has been configured with new
values (not default values).
Table 6-29: FlexCurve status
6.2.11 System info
This screen can be accessed at Actual> Status > System Info. It can monitor the system parameters and the internal status
of the Relay operating system.
Form firmware version prior to 7.00, System Info pop-up window shows general system information as described in the
table below:
Table 6-30: System info for firmware versions below 7.00
FLEX CURVES STATUS
FLEXCURVE A STATUS
FLEXCURVE B STATUS
FLEXCURVE C STATUS
FLEXCURVE D STATUS
SYSTEM INFO
E2PROM STATUS
DSP COMM ERROR
MAGNETIC MODULE ERROR
Green Zone
Yellow Zone
Orange Zone
Red Zone
Kswapd Time
mtd2 Time
mtd2 Time
CPU Rtai
CPU Linux
Total RAM
Used DRAM
Free RAM
Shared RAM
Buffer RAM
Chached RAM
Green Counter
Yellow Counter
Orange Counter
Red Counter
Up Time
