7-24 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
7.2.7.3.2 PICS for 650 family of relays whose order code has Rear Ethernet Communication Board 2
"H", "G", "K", "J","L", "M" and IEC 61850 Edition 2
Reference documentation: PICS for 650 family of relays v1_4 firm7_20.
This document describes the:
• ACSI Conformance Statement
• PICS ("Protocol Implementation Conformance Statement") for 650 family of relays.
1 ACSI Conformance Statement
The following ACSI conformance statements shall be used to provide an overview and details about a device claiming
conformance with ACSI to specify the communication features mapped to an SCSM:
• ACSI BASIC conformance statement.
• ACSI MODELS conformance statement.
• ACSI SERVICE conformance statement.
The statements specify the communication features mapped to IEC 61850-8-1 First Edition and/or Edition 2.
1.1 Notation
For the following clauses, these definitions apply:
• Y: The item is implemented.
• N: The item is not implemented.
• AA: Application Association.
• TP: Two-party (application association).
• MC: Multicast (application association).
1.2 ASCI basic conformance statement
The basic conformance statement is defined in Table 7-2: Basic conformance statement
Table 7-2: Basic conformance statement
Client/
Subscriber
Server/
Publisher
Value/ Comments
Client-Server roles
B11
Server side (of TWO-PARTY-APPLICATION-
ASSOCIATION)
- Y
B12
Client side of (TWO-PARTY-APPLICATION-
ASSOCIATION)
- N
SCSMs supported
B21 SCSM: IEC 6185-8-1 used - Y
B22 SCSM: IEC 6185-9-1 used - N Ed2:Deprecated
