CHAPTER 5: SETPOINTS 5.2 PRODUCT SETUP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 5-9
5.2.1.5 IEC 60870-5-104
Communication settings for IEC 60870-5-104 protocol. For more detailed information go to appendix D in this manual.
DNP protocol is available for standard and IEC61850 models but it is not available Procome models.
Table 5-6: IEC 60870-5-104 protocol settings
Analog Input Point 25 End of list N/A
Analog Input Point 26 End of list N/A
Analog Input Point 27 End of list N/A
Analog Input Point 28 End of list N/A
Analog Input Point 29 End of list N/A
Analog Input Point 30 End of list N/A
Analog Input Point 31 End of list N/A
Product Setup > Communication settings >IEC 870-5-104
Name Default Value Step Range
Function DISABLED N/A [DISABLED-UNICAST–BROADCAST-
ANY
CAST]
TCP Port 2404 1 [1 : 65535]
Common Addr of ASDU 255 1 [0 : 65535]
Cyclic Meter Period 0 1 [0 : 3600]
Synchronization Event 0 1 [0 : 3600]
IEC104 NET1 CLI1 OCTET1 0 N/A [0 : 255]
IEC104 NET1 CLI1 OCTET2 0 N/A [0 : 255]
IEC104 NET1 CLI1 OCTET3 0 N/A [0 : 255]
IEC104 NET1 CLI1 OCTET4 0 N/A [0 : 255]
IEC104 NET1 CLI2 OCTET1 0 N/A [0 : 255]
IEC104 NET1 CLI2 OCTET2 0 N/A [0 : 255]
IEC104 NET1 CLI2 OCTET3 0 N/A [0 : 255]
IEC104 NET1 CLI2 OCTET4 0 N/A [0 : 255]
Function 2 DISABLED N/A
TCP Port 2 2404 N/A [0 : 65535]
Common Addr of ASDU 2 255 N/A [0 : 65535]
IEC104 NET2 CLI1 OCTET1 0 N/A [0 : 255]
IEC104 NET2 CLI1 OCTET2 0 N/A [0 : 255]
IEC104 NET2 CLI1 OCTET3 0 N/A [0 : 255]
IEC104 NET2 CLI1 OCTET4 0 N/A [0 : 255]
IEC104 NET2 CLI2 OCTET1 0 N/A [0 : 255]
IEC104 NET2 CLI2 OCTET2 0 N/A [0 : 255]
IEC104 NET2 CLI2 OCTET3 0 N/A [0 : 255]
IEC104 NET2 CLI2 OCTET4 0 N/A [0 : 255]
IEC104 SCALE CURRENT 1 [0,00001; 0,0001; 0,001; 0,01; 0,1; 1; 10;
100; 1
000; 10000]
IEC104 SCALE VOLTAGE 1
IEC104 SCALE POWER 1 [0 : 65535]
IEC104 SCALE ENERGY 1 [0 : 65535]
IEC104 SCALE OTHER 1 [0 : 65535]
IEC104 DEADBAND CURRENT 30000 [0 : 65535]
IEC104 DEADBAND VOLTAGE 30000 [0 : 65535]
