5-8 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
5.2 PRODUCT SETUP CHAPTER 5: SETPOINTS
Voltage Scale Factor 1 N/A [0.00001-0.0001-0.001-0.01-0.1-1-10-
100-1000]
Power Scale Factor 1 N/A [0.00001-0.0001-0.001-0.01-0.1-1-10-
100-1000]
Energy Scale Factor 1 N/A [0.00001-0.0001-0.001-0.01-0.1-1-10-
100-1000]
Other Scale Factor 1 N/A [0.00001-0.0001-0.001-0.01-0.1-1-10-
100-1000]
Current Deadband 30000 1
[0 : 65535]
Product Setup > Communication settings >DNP3 Slave
DNP3 Slave 1 > DNP3 Slave 2 > DNP3 Slave 3
Voltage Deadband 30000 1 [0 : 65535]
Power Deadband 30000 1 [0 : 65535]
Energy Deadband 30000 1 [0 : 65535]
Other Deadband 30000 1 [0 : 65535]
Msg Fragment Size 240 1 [30 : 2048]
Binary Input Block 1 CTL EVENTS 1-16 N/A
Binary Input Block 2 CTL EVENTS 17-32 N/A
Binary Input Block 3 CTL EVENTS 33-48 N/A
Binary Input Block 4 CTL EVENTS 49-64 N/A
Binary Input Block 5 CTL EVENTS 65-80 N/A
Binary Input Block 6 CTL EVENTS 81-96 N/A
Binary Input Block 7 CTL EVENTS 97-112 N/A
Binary Input Block 8 CTL EVENTS 113-128 N/A
Binary Input Block 9 SWITCHGEAR 1-8 N/A
Binary Input Block 10 SWITCHGEAR 9-16 N/A
Default Analog Map ENABLED N/A
Analog Input Point 0 End of list N/A
Analog Input Point 1 End of list N/A
Analog Input Point 2 End of list N/A
Analog Input Point 3 End of list N/A
Analog Input Point 4 End of list N/A
Analog Input Point 5 End of list N/A
Analog Input Point 6 End of list N/A
Analog Input Point 7 End of list N/A
Analog Input Point 8 End of list N/A
Analog Input Point 9 End of list N/A
Analog Input Point 10 End of list N/A
Analog Input Point 11 End of list N/A
Analog Input Point 12 End of list N/A
Analog Input Point 13 End of list N/A
Analog Input Point 14 End of list N/A
Analog Input Point 15 End of list N/A
Analog Input Point 16 End of list N/A
Analog Input Point 17 End of list N/A
Analog Input Point 18 End of list N/A
Analog Input Point 19 End of list N/A
Analog Input Point 20 End of list N/A
Analog Input Point 21 End of list N/A
Analog Input Point 22 End of list N/A
Analog Input Point 23 End of list N/A
Analog Input Point 24 End of list N/A
