APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-21
B.5 Memory map
The Memory map can be obtained from EnerVista 650 Setup software, menu:
View > ModBus Memory map
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
Estado CPU - CPU Status
0x0003 0x0100 TIMER STATUS F001 R 1
0x0003 0x0200 E2PROM STATUS F001 R 1
Salidas Virtuales (512 elementos) - Virtual Outputs
0x0005 0x0400 VIRTUAL OUTPUT 000 F001 R 1
0x0005 0x0800 VIRTUAL OUTPUT 001 F001 R 1
... ... ... ... ... ... ... ...
0x0025 0x0200 VIRTUAL OUTPUT 511 F001 R 1
Salidas virtuales analógicas- Virtual Output Analog
0x07D0 INT32_000 F005 1.000 R 2
0x07D2 INT32_001 F005 1.000 R 2
0x07D4 INT32_002 F005 1.000 R 2
0x07D6 INT32_003 F005 1.000 R 2
0x07D8 INT32_004 F005 1.000 R 2
0x07DA INT32_005 F005 1.000 R 2
0x07DC INT32_006 F005 1.000 R 2
0x07DE INT32_007 F005 1.000 R 2
0x07E0 INT32_008 F005 1.000 R 2
0x07E2 INT32_009 F005 1.000 R 2
0x07E4 INT32_010 F005 1.000 R 2
0x07E6 INT32_011 F005 1.000 R 2
0x07E8 INT32_012 F005 1.000 R 2
0x07EA INT32_013 F005 1.000 R 2
0x07EC INT32_014 F005 1.000 R 2
0x07EE INT32_015 F005 1.000 R 2
0x07F0 INT32_016 F005 1.000 R 2
0x07F2 INT32_017 F005 1.000 R 2
0x07F4 INT32_018 F005 1.000 R 2
0x07F6 INT32_019 F005 1.000 R 2
0x07F8 INT32_020 F005 1.000 R 2
0x07FA INT32_021 F005 1.000 R 2
0x07FC
INT32_022 F005 1.000 R 2
0x07FE INT32_023 F005 1.000 R 2
0x0800 INT32_024 F005 1.000 R 2
0x0802 INT32_025 F005 1.000 R 2
0x0804 INT32_026 F005 1.000 R 2
0x0806 INT32_027 F005 1.000 R 2
0x0808 INT32_028 F005 1.000 R 2
0x080A INT32_029 F005 1.000 R 2
0x080C INT32_030 F005 1.000 R 2
0x080E INT32_031 F005 1.000 R 2
0x0810 INT32_032 F005 1.000 R 2
0x0812 INT32_033 F005 1.000 R 2
0x0814 INT32_034 F005 1.000 R 2
0x0816 INT32_035 F005 1.000 R 2
