GEK-106310-AF F650 DIGITAL BAY CONTROLLER 9-1
F650 Digital Bay Controller
Chapter 9: Bootcode and firmware upgrade
GE
Grid Solutions
BOOTCODE AND FIRMWARE UPGRADE
9.1 Firmware upgrade versions below 7.00.
This section explains how to upgrade the F650 boot code and firmware for version below 7.00.
The boot code and firmware versions can be seen in the relay main screen: The relay firmware version appears after the
text “F650“(5.70 in Figure 9-1: Main screen) with the boot program version (6.00 in Figure 9-1: Main screen) followed by
“GENERAL ELECTRIC”, the relay model and the default front RS232/USB port communication parameters.
Figure 9-1: Main screen
BEFORE PERFORMING THE UPGRADE PROCEDURE CHECK THAT BOOT AND FIRMWARE VERSION
MATCH.
