6-50 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
6.4 INPUTS / OUTPUTS CHAPTER 6: ACTUAL VALUES
6.4.9 Remote inputs
Actual > Inputs/Outputs > Remote Intputs > Remote Input
This screen provides the status of the 32 remote inputs.
Actual > Inputs/Outputs > Remote Intputs > Remote Device
This screen provides the status of the 16 remote devices.
Actual > Inputs/Outputs > Remote Outputs > Remote GOOSE Digital Inputs
This screen provides the status of the 32 Remote GOOSE Digital Inputs.
Actual > Inputs/Outputs > Remote Outp
uts > Remote GOOSE Analog Inputs
This screen provides the values of the 16 Remote GOOSE Analo
g Inputs. Eight of them are float type and the other eight
are integer type.
remote inputs STATUS
Remote Input 1
Remote Input 2
Remote Input 3
...
Remote Input 32
remote device STATUS
Remote Device 1
Remote Device 2
Remote Device 3
...
Remote Device 16
REMOTE GOOSE DIG INPUTS STATUS
Rem GOOSE Dig Inp 1
Rem GOOSE Dig Inp 2
Rem GOOSE Dig Inp 3
...
Rem GOOSE Dig Inp 32
REMOTE GOOSE ANALOG INPUTS STATUS
Rem Ana Inp FLOAT 1
Rem Ana Inp FLOAT 2
Rem Ana Inp FLOAT 3
...
Rem Ana Inp FLOAT 8
Rem Ana Inp INT 1
Rem Ana Inp INT 2
Rem Ana Inp INT 3
...
Rem Ana Inp INT 8
To Next Page
