6-6 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
6.2 STATUS CHAPTER 6: ACTUAL VALUES
6.2.3.6 Negative sequence current
This screen shows the pickup and trip for negative sequence elements in the F650. Any of these two events of any ground
element lights up the corresponding LED in this screen, and it remains lit while the associated function remains in pickup or
operation.
This screen is accessed in menu: Actual> Status > Protection >Negative Sequence Current, and includes the following
signaling LEDs:
Table 6-6: Negative sequence current actual values
6.2.3.7 Thermal model
F650 units incorporate up to 3 thermal image elements. For each of them, this screen shows by means of green LEDs, the
activation of the reset, alarm, operation and thermal image signals for each phase (A, B, C) and each unit (1, 2, 3). Any of the
reset, alarm and operation signals light up the corresponding LED in this screen, and it remains lit as the associated
function remains in reset, pickup or operation. This function also provides the thermal image value for all the phases and
functions in percentage. All the values are provided individually for phases and for the three thermal elements.
This screen is accessed in menu: Actual> Status > Protection >Thermal image, and includes the following signaling LEDs:
Table 6-7: Thermal model actual values
NEGATIVE SEQUENCE TOC ACTUAL VALUES
NEG SEQ TOC1 PKP
NEG SEQ TOC1 OP
NEG SEQ TOC2 PKP
NEG SEQ TOC2 OP
NEG SEQ TOC3 PKP
NEG SEQ TOC3 OP
THERMAL IMAGE RESET
SIGNALS
THERMAL IMAGE ALARM
SIGNALS
THERMAL IMAGE OPERATION
SIGNALS
THERMAL IMAGE VALUE
IN %
THERMAL1 ALARM THERMAL1 OP
THERMAL1 A RST THERMAL1 A ALARM THERMAL1 A OP THERMAL1 IMAGE A
THERMAL1 B RST THERMAL1 B ALARM THERMAL1 B OP THERMAL1 IMAGE B
THERMAL1 C RST THERMAL1 C ALARM THERMAL1 C OP THERMAL1 IMAGE C
THERMAL2 ALARM THERMAL2 OP
THERMAL2 A RST THERMAL2 A ALARM THERMAL2 A OP THERMAL2 IMAGE A
THERMAL2 B RST THERMAL2 B ALARM THERMAL2 B OP THERMAL2 IMAGE B
THERMAL2 C RST THERMAL2 C ALARM THERMAL2 C OP THERMAL2 IMAGE C
THERMAL3 ALARM THERMAL3 OP
THERMAL3 A RST THERMAL3 A ALARM THERMAL3 A OP THERMAL3 IMAGE A
THERMAL3 B RST THERMAL3 B ALARM THERMAL3 B OP THERMAL3 IMAGE B
THERMAL3 C RST THERMAL3 C ALARM THERMAL3 C OP THERMAL3 IMAGE C
