CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-41
7.2.7.3.4 MICS for 650 family of relays whose order code has Rear Ethernet Communication Board 2
option "B", "C", "D", "E" and IEC 61850 Edition 1
Reference documentation: MICS for 650 family rev1.4 firm3_60.
This document describes the:
• Logical Nodes List
• Logical Nodes and Extensions
• Enum types implementation
1 Logical Nodes List
The following table contains the list of logical nodes implemented in the device with firmware version lower than 7.00:
2 Logical Nodes and Extensions
Some of the following logical nodes have been extended with extra data. All extra data has been highligthed in the tables
and marked as “E” (Extended), these data contains “dataNs” attribute with the NameSpace “GE MICS for 650 family
rev1.3”.
Comments:
ØM: Data is mandatory in the IEC-61850-7-4.
ØO: Data is optional in the IEC-61850-7-4 and is used in the device.
ØE: Data is an extension to the IEC-61850-7-4.
L: System Logical Nodes
LPHD (
Physical device information)
LLN0 (Logical node zero)
P: Logical Nodes for protection functions
PIOC (Inst
antaneous overcurrent)
PTOC (T
ime overcurrent)
PTOF (O
verfrequency)
PTOV (O
vervoltage)
PTUV (Und
ervoltage)
PTUF (Underfrequency)
R: Logical nodes for protection related functions
RDIR (Dir
ectional element)
RREC (Autoreclosing)
C: Logical Nodes for control
CSWI (Switch controller)
G: Logical Nodes for generic references
GGIO (Generic process I/O)
M: Logical Nodes for metering and measurement
MMTR (M
etering)
MMXU (Mea
surement)
MSQI (Sequence and imbalance)
X: Logical Nodes for switchgear
XCBR (C
ircuit breaker)
XSWI (C
ircuit switch)
