7-42 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.1 System Logical Nodes. LN Group: L
2.1.1LPHD (Physical device information)
2.1.2 LLN0 (Logical node zero)
2.1.2.1 GsCB (GSSE control block class definition)
2.1.2.2 GoCB (GOOSE control block class definition)
LPHD class
Attribute Name Attribute Type Explanation M/O/E Notes
LPHD Physical device information M
Data
Common Logical Node Information
PhyNam DPL Physical device name plate M
PhyHealth INS Physical device health M
Proxy SPS Indicates if this LN is a proxy M
LLN0 class
Attribute Name Attribute Type Explanation M/O/E Notes
LLN0 Logical node zero
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Loc SPS Local operation for complete logical device O
Optmh INS Operation time M
GsCB (ACSI class GSSE control block)
Gs C B Gs C B
GoCB (ACSI class GOOSE control block)
GoCB GoCB
SGCB (ACSI class Setting Group control block)
SGCB SGCB
GsCB class
Attribute Name Attribute Type FC Notes
Gs E n a BOOLEAN GS Enable (TRUE), disable (FALSE)
Gs I D VISIBLE STRING65 GS
DNALabels[1..n] VISIBLE STRING65 GS Labels of DNA bit pairs
UserSTLabels[1..n] VISIBLE STRING65 GS Label of ST bit pairs
LSentData [1..n] GSSEData GS Derived from GSSE message
GoCB class
Attribute Name Attribute Type FC Notes
GoEna BOOLEAN GO Enable (TRUE), disable (FALSE)
GoID VISIBLE STRING65 GO
