GE Multilin F650 - F.1 IEC 60870-5-103 Protocol

GEK-106310-AF F650 DIGITAL BAY CONTROLLER f-1
F650 Digital Bay Controller
Appendix F: IEC 60870-5-103 PROTOCOL
GE
Grid Solutions
IEC 60870-5-103 PROTOCOL
F.1 IEC 60870-5-103 protocol
F.1.1 Interoperability document
The F650 implements functionality of an IEC 60870-5-103 server.
This section describes the protocol IEC 60870-5-103 implementation in the unit.
1. PHYSICAL LAYER
Electrical interface
Optical interface
Transmission speed
2. LINK LAYER
There are no choices for the link layer.
3. APPLICATION LAYER
X EIA RS-485
32 Number of loads for one protection equipment
X Glass fibre
X Plastic fibre
F-SMA type connector
X BFOC/2,5 type connector
X 9600 bits/s
X 19200 bits/s
