E-2 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
E.1 PROCOME PROTOCOL APPENDIX E: PROCOME PROTOCOL
- Primary to Secondary.
ASDU 121 Commands
- Secondary to Primary.
ASDU 121 Commands
f) Clock Synchronization
- Primary to Secondary.
ASDU 6 Clock Synchronization
-Secondary to Primary:
ASDU 6 Clock Synchronization
Procome Settings:
When value NONE is selected in the COMM Port setting the protocol is not enabled. The COM1 selection enables PROCOME
for the COM1 (remote) serial port.
Slave Number:is the PROCOME slave number.
Baud rate and parity for COM1 must be set in Setpoint > Communications > Serial Ports.
Procome Configuration:
The procome data configuration is performed through the Setpoint > Procome Configuration tool when communicating
via Ethernet with the device. The procome configuration file can be retrieved and sent to the relay easily. The relay must
be switched off and on to start working with the new procome configuration set by the user. The relay by default has no
procome configuration. For more information about procome configuration see 5.13 IEC 60870-5-103 configuration.
Product Setup > Communication Settings > PROCOME
Name Default Value Step Range
COMM Port NONE [NONE - COM1]
Slave Number 0
[0 : 254]
