CHAPTER 4: INTERFACES, SETTINGS & ACTUAL VALUES 4.2 HUMAN-MACHINE INTERFACE (HMI)
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 4-59
Pressing the up-down key or rotating the shuttle key to the left (L) or right (R) the user can access all the Metering values in
the screen.
4.2.7.3 All events screen
This screen shows all events that have been produced in the relay. The top of the screen shows its name (All Events), and
the relative and total number of events contained in the screen.
All Events (1/479) or (1/511 for Firmware version 7.20 or higher)
This legend means that there are a total of events stored in the relay, and that the cursor is located on event number 1.
The information shown on this screen for each event is as follows:
"Hour:Minute:Second:Millisecond" "Event text" "Event status (ON/OFF)"
Figure 4-34: All events screen
The screen legend options are:
Esc: Prev. Enter: Menu. : Scroll.
METERING SCREEN ANALOG MEASURES IN PRIMARY VALUES
Phasor Ia Primary V0 Primary Phase A Real Pwr Line Frequency Primary
Phasor Ib Primary V1 Primary Phase B Reactive Pwr Bus Frequency Primary
Phasor Ic Primary V2 Primary Phase B Apparent Pwr Vx Primary
Phasor Ig Primary Vab Primary Phase B Real Pwr Pos MVarhour Freeze
Phasor Isg Primary Vbc Primary Phase C Reactive Pwr NegMVarhour Freeze
Phasor In Primary Vca Primary Phase C Apparent Pwr PosMWatthour Freeze
RMS Ia Primary Vn Primary Phase C Real Pwr Neg MWatthour Freeze
RMS Ib Primary Va Primary 3 Phase Reactive Pwr Positive MVarhour
RMS Ic Primary Vb Primary 3 Phase Apparent Pwr Negative MVarhour
RMS Ig Primary Vc Primary 3 Phase Real Pwr Positive MWatthour
RMS Isg Primary VL Primary Phase A Power Factor Negative MWatthour
I0 Primary VBB Primary Phase B Power Factor % of Load-to-trip
I1 Primary Phase A Reactive Pwr Phase C Power Factor
I2 Primary Phase A Apparent Pwr 3 Phase Power Factor
All Events (1/479).
- [ Ready LED ON ] -
16:11:08.035 Ready LED ON ON
16:11:08.017 Breaker Closed ON ON
16:11:08.005 Isolated Gnd3 Block OFF OFF
16:11:08.005 Isolated Gnd2 Block OFF OFF
16:11:08.005 Isolated Gnd1 Block OFF OFF
16:11:08.005 Sens Gnd TOC3 Block OFF OFF
16:11:08.005 Sens Gnd TOC2 Block OFF OFF
16:11:08.005 Sens Gnd TOC1 Block OFF OFF
16:11:08.005 Ground TOC3 Block OFF OFF
16:11:08.005 Ground TOC2 Block OFF OFF
16:11:08.005 Ground TOC1 Block OFF OFF
Esc: Prev. Ente
