GE Multilin F650 - Nication Board 2 Option H, G, K, J, L, M and IEC 61850 Edition 1

7-182 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
7.2.7.3.9 TICS for 650 family of relays whose order code has Rear Ethernet Communication Board 2
option "H", "G", "K", "J", "L", "M" and IEC 61850 Edition 1
Reference documentation: TICS For F650 relay V3_05 firm7_52
Mandatory Intop Tissues
During the October 2006 meeting IEC TC57 working group 10 decided that:
• green Tissues with the category "IntOp" are mandatory for IEC 61850 edition 1
• Tissues with the category "Ed.2" Tissues should not be implemented.
The table below gives an overview of the implemented IntOp Tissues.
Part Tissue
Nr
Description Implemented
Y/na
8-1 116
165
183
246
545
GetNameList with empty response?
Improper Error Response for GetDataSetValues
GetNameList error handling
Control negative response (SBOns) with LastApplError
Skip file directories with no files
Y
na
na
na
na
7-4 252 AlmThm should have CDC SPS Y
7-3 28
54
55
63
65
219
270
1199
Definition of APC
Point def xVal, not cVal
Ineut = Ires ?
mag in CDC CMV
Deadband calculation of a Vector and trigger option
operTm in ACT
WYE and DEL rms values
BCR
na
na
na
na
na
na
na
na
