• Temp Max Value: Maximum temperature reached by CPU during operating mode. This value is reset
This value is taken into account from last reboot.
• Te
mp Min Value: Maximum temperature reached by CPU after last reboot.
• Scan Cy
cle Average: Mean time in nanoseconds that takes a Scan cycle to run
• Scan Cy
cle Rate: Every miliseconds a Scan cycle is run
• P
LC Checksum: Value of CRC of PLC equations. This value is read from the relay.
• Se
ttings checksum: Value of CRC of relay settings. This value is read from the relay.
• MA
C address: MAC address assigned to Ethernet port, Eth_E.
• Se
rial number: Serial number of the relay that is communicating with Enervista 650 Setup.
• Manufacturing dat
e: Date when the relay, connected to Enervista 650 Setup, was assembled.
6.2.12 Record status
This screen shows part of the information related to the different records stored in the Relay, such as:
6.2.12.1 Fault reports
Actual> Status > Records Status > Fault Reports
Table 6-32: Fault report status
FAULT REPORT STATUS
FAULT REPORT TRIGG
CLEAR FAULT REPORTS
PreFault Ia Mod
PreFault Ia Ang
PreFault Ib Mod
PreFault Ib Ang
PreFault Ic Mod
PreFault Ic Ang
PreFault Vab Mod
PreFault Vab Ang
PreFault Vbc Mod
PreFault Vbc Ang
PreFault Vca Mod
PreFault Vca Ang
PreFault Ig Mod
PreFault Ig Ang
PreFault Isg Mod
PreFault Isg Ang
PostFault Ia Mod
PostFault Ia Ang
PostFault Ib Mod
PostFault Ib Ang
PostFault Ic Mod
PostFault Ic Ang
PostFault Vab Mod
PostFault Vab Ang
PostFault Vbc Mod
PostFault Vbc Ang
PostFault Vca Mod
