CHAPTER 6: ACTUAL VALUES 6.4 INPUTS / OUTPUTS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 6-47
6.4.4 Contact output resets
Actual > Inputs/Outputs > Contact Output Resets > Board X (being X the corresponding board in each case).
Boards types 1 and 2 have both 8 outputs, so the representation is the same for both types as shown in
If the reset signal is active, the green LED lights up. Otherwise, it remains unlit.
The last LED in this screen, labeled Board Status, indicates the general board status.
This output reset Command is only be effective if latch has been selected for Output Type on the I/O board, thus the
contact output has been configured to emulate function 86 (latching relay).
Configuration for the contact output reset signal is set at Setpoint > Relay Configuration > Outputs > Contact Output
Reset.
6.4.5 I/O board status
Actual > Inputs/Outputs > I/O Board Status
This screen is used for verifying the status of I/O boards. If all the I/O boards, one (F) or both (F and G) depending on the
relay model, are correctly inserted in their tracks and are in good state and communicating through the internal CAN bus,
the green LED remains lit.
I/O boards accessible through the external CAN bus are labeled as H and J. In order to start working with the external I/O
boards is necessary to select the appropriated I/O board type for each slot (H or J for the CIO module) at Setpoint >
Inputs/Outputs >Contact I/O > Board H and J. Otherwise the relay will not start communicating through the external
CAN bus to the related board.
If one of the boards has been extracted, or the relay model does not match the installed hardware, the corresponding LED
remains unlit.
For all I/O board screens described above, the last LED provides this same information individually.
CONTACT OUTPUT RESETS
CONT OP RESET_X_01
CONT OP RESET_X_02
CONT OP RESET_X_03
CONT OP RESET_X_04
CONT OP RESET_X_05
CONT OP RESET_X_06
CONT OP RESET_X_07
CONT OP RESET_X_08
BOARD X STATUS
I/O BOARD STATUS
BOARD F STATUS
BOARD G STATUS
BOARD H STATUS
BOARD J STATUS
