CHAPTER 2: PRODUCT DESCRIPTION 2.4 ORDER CODES
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 2-5
2.4 Order codes
F650 units are supplied as ½ 19” rack, 6 units high, containing the following modules: power supply, CPU, I/O modules,
communication modules. The required information to completely define an F650 model is shown on Table 2–1:
Table 2-1: Order codes
F650 - - - F - G - - - - - DESCRIPTION
B Basic Display (See Note 2)
M Graphic Display with Standard Symbols (See Note 2)
N Graphic Display with IEC symbols (See Note 2)
REAR SERIAL COMMUNICATIONS BOARD 1
F None
A Redundant RS485
P Redundant plastic fiber optic
G Redundant glass fiber optic
X Redundant RS485 + fiber remote CAN bus I/O
Y Redundant plastic fiber optic + fiber remote CAN bus I/O
Z Redundant glass fiber optic + fiber remote CAN bus I/O
C Cable Remote CAN bus I/O
M RS485 + cable Remote CAN bus I/O
REAR ETHERNET COMMUNICATIONS BOARD 2
B 10/100 Base TX
C 10/100 Base TX + 100 Base FX
D 10/100 Base TX + Redundant 100 Base FX
E Redundant 10/100 Base TX
G 1588, 10/100 Base TX* + 100 Base TX (See Note 3)
H 1588, 10/100 Base TX* + 100 Base FX (See Note 3)
J PRP, 1588, 10/100 Base TX* + Redundant 100 Base FX (See Note 4)
K PRP, HSR, RSTP, 1588, 10/100 Base TX* + Redundant 100 Base FX
(See not
e4)
L PRP, 1588, 10/100 Base TX*+ Redundant 100 Base TX (See Note 4)
M PRP, HSR, RSTP, 1588, 10/100 Base TX*+ Redundant 100 Base TX
(See Not
e 4)
I/O BOARD IN SLOT F
1 16 Digital Inputs + 8 Outputs
2 8 Digital Inputs + 8 Outputs + 2 trip/close circuit supervision circuits
4 32 Digital Inputs
5 16 Digital Inputs + 8 Analog Inputs
I/O BOARD IN SLOT G
0 None
1 16 Digital Inputs + 8 Outputs
4 32 Digital Inputs (see Note 1)
5 16 Digital Inputs + 8 Analog Inputs (See Note 1)
AUXILIARY VOLTAGE
LO 24-48 Vdc (range 19.2 – 57.6)
HI
110-250 Vdc (range 88 – 300).
120-230 Vac (range 96 – 250)
LOR Redundant LO
HIR Redundant HI
LANGUAGE
- English/English
C Chinese/English (See Note 2and Note 7)
