2-6 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
2.4 ORDER CODES CHAPTER 2: PRODUCT DESCRIPTION
SPECIAL MODELS MOD001 (Abbreviation "+M1"): have 6A output contacts instead of 16A.
Notes:
(*) For firmware version 7.00 or above, Port
E is intended for maintenance purposes.
(1) The digit selected for option G must be equal or higher than the d
igit selected for option F for models including boards 4 and 5
only.
F1G5 is a valid selection and F5G1 is an invalid selection.
(2) Display options with language selection:
Graphic display: available for English, French, Spanish and Chinese languages. For Chinese and Russian only IEC symbols option is
available (N in order code).
Basic display: available for all languages
(3) Advance functionalities Level I:
G, H: IEEE1588 Precision Time Protocol (PTP), 61850 Edition 2.0. Digital counters. Max numbers of starts and Cold Load Pick-up
functionalities.
(4) Advance functionalities Level II:
J, L: Parallel Redundancy Port (PRP,) IEEE1588 Precision Time Protocol (PTP), 61850 Edition 2.0. Digital counters, DFT, 16 Switchgear
mapped in IEC61850, 16 nodes CILO, mapping of BlkOpn and BlkCls leafs of XSWI nodes, Max numbers of starts and Cold Load Pick-
up functionalities.
K, M: High-Availability Seamless Redundancy (HSR), Rapid Spanning Tree Protocol (RSTP), Parallel Redundancy Port (PRP,) IEEE1588
Precision Time Protocol (PTC), 61850 Edition 2.0. Digital counters, DFT, 16 Switchgear mapped in IEC61850, 16 nodes CILO, mapping of
BlkOpn and BlkCls leafs of XSWI nodes, Max numbers of starts and Cold Load Pick-up functionalities.
(5) For special models requested, relay order code shall be codified as a standard model (Table 2-1) following by Abbreviation + MX where X
indicates the number of special model selected.
(6) For non-last released firmware version models requested, relay order code shall be codified as standard model (Table 2-1), following
by Abbreviation +VXXXXXBYYYYY where XXXXX is the firmware version requested and YYYYY is the corresponding bootcode version.
(7) Chinese Language: This language is not supported for Rear Ethernet Communication Board options: G, H, J,K,L or M
(8) Display option with RS232 is not available for F650 Models with Rear Ethernet Communication Board 2 options from G to M or with
Environmental Protection option M
(9) Marine Range option M in the Environmental Protection section is only available with REAR ETHERNET COMMUNICATIONS BOARD 2
options G,H,J,K,L or M
(10) For F650 whose order code has Communication Option "6", Rear Ethernet Communication Board 2 and that contains firmware version
7.52, IEC 61850 Edition 1.0 is also available in relays with this option selected. Relay will work with IEC 61850 Edition 1.0 or Edition 2.0
depend on which ICD have been sent to the device. See section
F French/English
P Russian/English (See Note 2)
S Spanish/English
T Turkish/English
COMMUNICATION PROTOCOL
- Modbus® RTU, TCP/IP, DNP 3.0 Level 2, IEC 60870-5-104
3 IEC 60870-5-103, Modbus® RTU,TCP/IP
6
IEC 61850 (See Note 10), Modbus® RTU and TCP/IP,DNP 3.0 Level 2,
IEC 60870-5-104
ENVIRONMENTAL PROTECTION
- Without Harsh (Chemical) Environment Conformal Coating
H Harsh (Chemical) Environment Conformal Coating
M Marine range: Lloyd’s Register (See Note 9)
ENHANCED DISPLAY
- Display with RS232 (See Note 8)
E Enhanced Display with USB
