GE Multilin F650 - Virtual Inputs; Virtual Outputs; Remote Outputs

6-48 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
6.4 INPUTS / OUTPUTS CHAPTER 6: ACTUAL VALUES
6.4.6 Virtual inputs
Actual > Inputs/Outputs > Virtual Inputs > Virtual Input Latched > Virtual Input Self-Reset
“Virtual Inputs” are signals transmitted by communications. The EnerVista 650 Setup provides a tool to set virtual inputs
through ModBus at Setpoint > Inputs /Outputs /Virtual inputs that is only available in online mode (communicating to
the relay). There are two available groups of 32 signals each: Latched inputs and Self-reset inputs, and all of them can be
used internally to perform operations, new logics in the PLC, etc.
In this actual values screen the status of the assigned virtual inputs can as shown on
6.4.7 Virtual outputs
Actual > Inputs/Outputs > Virtual Outputs
This screen provides the status of the 512 configurable virtual outputs (internal variables) used in the logic scheme. The
virtual outputs are set from 000 to 511.
The configuration of the logic associated with the virtual output is in the Setpoint > Logic Configuration tool provided by
EnerVista 650 Setup program.
6.4.8 Remote outputs
Actual > Inputs/Outputs > Remote Outputs > DNA
This screen provides the status of the 32 DNA remote outputs.
Table 6-40: DNA STATUS
VIRTUAL INPUTS LATCHED VIRTUAL INPUTS SELF-RESET
LATCHED VIRT IP 1 SELF-RST VIRT IP 1
LATCHED VIRT IP 2 SELF-RST VIRT IP 2
… …
LATCHED VIRT IP 32 SELF-RST VIRT IP 32
VIRTUAL OUTPUT STATUS
VIRTUAL OUTPUT 000
VIRTUAL OUTPUT 001
…
VIRTUAL OUTPUT 511
DNA STATUS
DNA 1
DNA 2
DNA 3
...
DNA 32
