F-2 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
F.1 IEC 60870-5-103 PROTOCOL APPENDIX F: IEC 60870-5-103 PROTOCOL
Transmission mode for application data
Mode 1 (least significant octet first), as defined in 4.10 of IEC 60870-5-4, is used exclusively in this companion standard.
Common address of ASDU
Selection of standard information numbers in monitor direction
System functions in monitor direction
Status indications in monitor direction
Supervision indications in monitor direction
X One COMMON ADDRESS OF ASDU (identical with station address)
More than one COMMON ADDRESS OF ASDU
INF Semantics
X <0> End of general interrogation
X <0> Time synchronization
X <2> Reset FCB
X <3> Reset CU
X <4> Start/restart
X <5> Power on
INF Semantics F650 Identifier F650 Data Text
X <16> Auto-recloser active 4591 AR READY
X <17> Teleprotection active 3895 LOCAL
<18> Protection active
X <19> LED reset 6839 RESET LEDS
<20> Monitor direction blocked
<21> Test mode
<22> Local parameter setting
X <23> Characteristic 1 4875 GROUP 1 ACT ON
X <24> Characteristic 2 4876 GROUP 2 ACT ON
X <25> Characteristic 3 4877 GROUP 3 ACT ON
<26> Characteristic 4
<27> Auxiliary input 1
<28> Auxiliary input 2
<29> Auxiliary input 3
<30> Auxiliary input 4
INF Semantics F650 Identifier F650 Data Text
<32> Measurand supervision I
<33> Measurand supervision V
