CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-25
1.3 ACSI models conformance statement
The ACSI models conformance statement is defined in Table 7-3: ACSI models conformance statement.
Table 7-3: ACSI models conformance statement
B23 SCSM: IEC 6185-9-2 used - N
B24 SCSM: other - N
Generic substation event model (GSE)
B31 Publisher side - Y
B32 Subscriber side Y -
Transmission of sampled value model (SVC)
B41 Publisher side
B42 Subscriber side
–
Y = supported
N or empty = not supported
Client/
Subscriber
Server/
Publisher
Value/
Comments
If Server or Client side (B11/12) supported
M1 Logical device - Y
M2 Logical node - Y
M3 Data - Y
M4 Data set - Y
M5 Substitution
M6 Setting group control - Y
Reporting
M7 Buffered report control - Y
M7-1 sequence-number - Y
M7-2 report-time-stamp - Y
M7-3 reason-for-inclusion - Y
M7-4 data-set-name - Y
M7-5 data-reference - Y
M7-6 buffer-overflow - Y
M7-7 entryID - Y
M7-8 BufTm - Y
M7-9 IntgPd - Y
M7-10 GI - Y
M7-11 conf-revision - Y
M8 Unbuffered report control - Y
M8-1 sequence-number - Y
M8-2 report-time-stamp - Y
M8-3 reason-for-inclusion - Y
M8-4 data-set-name - Y
M8-5 data-reference - Y
M8-6 BufTm - Y
M8-7 IntgPd - Y
M8-8 GI - Y
