7-26 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
1.4 ACSI service conformance statement
The ACSI service conformance statement is defined in Table 7-4: ACSI service conformance statement.
Table 7-4: ACSI service conformance statement
M8-9 conf-revision - Y
Logging
M9 Log control -
M9-1 IntgPd -
M10 Log -
M11 Control - Y
M17 File Transfer Y
M18 Application association Y
M19 GOOSE Control Block Y
M20 Sampled Value Control Block
If GSE (B31/32) is supported
M12 GOOSE Y
M13 GSSE Deprecated
If SVC (B41/B42) is supported
M14 Multicast SVC
M15 Unicast SVC
For all IEDs
M16 Time Y Y
Y = service is supported
N or empty = service is not supported
Ed ACSI Service
AA:
TP/MC
Client
Sub(C)
Server
Pub(S)
Comments
Server
S1 1,2
GetServerDirectory(LOGICAL-
DEVICE)
TP Y
Application association
S2 1,2 Associate TP Y
S3 1,2 Abort TP Y
S4 1,2 Release TP Y
Logical device
S5 1,2 GetLogicalDeviceDirectory TP Y
Logical node
S6 1,2 GetLogicalNodeDirectory TP Y
S7 1,2 GetAllDataValues TP Y
Data
S8 1,2 GetDataValues TP Y
S9 1,2 SetDataValues TP Y
S10 1,2 GetDataDirectory TP Y
S11 1,2 GetDataDefinition TP Y
Data set
S12 1,2 GetDataSetValues TP Y
