6-28 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
6.2 STATUS CHAPTER 6: ACTUAL VALUES
• E2PROM status: LED associated lights in green if E2PROM is configured and working properly
• DSP comm err
or: LED associated lights in green if communication error between DSP and main processor.
• Magnetic module err
or: LED associated lights in green if communication error between DSP and magnetic module.
• Gr
een/Yellow/Orange/Red Zones and Counters:
These 4 counters are referred to the total amount of free RAM available in the device. The
usual
state should be Green zone and the rest of indicators means that the device can
have or stop some task just in case that they would need to prioritize the protection task.
• Kswapd T
ime: It should take value always to 0
• Mt
d2 Time: Time accessing to this partition with Linux OS
• Mt
d3 Time: Time accessing to this partition with Application
• CPU Rtai: P
ercentage corresponding to protection tasks execution
• CPU L
inux: Percentage corresponding to rest of linux tasks execution
• To
tal RAM: Total RAM in the device
• Used DRAM: Used
RAM in the device
• Fr
ee RAM: Available RAM in the device
• Chache
d RAM: Memory reserved for the Linux OS
• Up T
ime: Second from the last power-up
• DS
P Counter: It shows that DSP is running
• IC
D Status: Information about status of ICD file stored in the F650. For detailed information go to
Chapter 7, section 7.3.2.2 IEC 61850 CONFIGURATOR FEATURES FOR CONFIGURATION
• MA
C address: MAC address assigned to Ethernet ports, Eth_1 and Eth_2.
• Se
rial number: Serial number of the relay that is communicating with Enervista 650 Setup.
• Manufacturing dat
e: Date when the relay, connected to Enervista 650 Setup, was assembled.
Table 6-31: System info for firmware versions 7.00 and above
DSP Counter
ICD Status
MAC Address
Serial Number
Manufacturer date
SYSTEM INFO
E2PROM STATUS
DSP COMM ERROR
MAGNETIC MODULE ERROR
PLC ERROR
NET CONF ERROR
ORDER CODE ERROR
Total RAM
Used DRAM
Free RAM
Up Time
