7-66 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
Nodes with ** in the table above have been included from firmware version 7.50
2 Logical Nodes and Extensions
Notation:
ØM: Data is mandatory in the IEC-61850-7-4.
ØO: Data is optional in the IEC-61850-7-4 and is used in the device.
ØE: Data is an extension to the IEC-61850-7-4.
2.1 System Logical Nodes. LN Group: L
2.1.1LPHD (Physical device information)
2.1.2 LLN0 (Logical node zero)
G: Logical Nodes for generic references
GGIO (Generic process I/O)
M: Logical Nodes for metering and measurement
MMTR (Metering)
MMXU (Measurement)
MSQI (Sequence and imbalance)
X: Logical Nodes for switchgear
XCBR (Circuit breaker)
XSWI (Circuit switch)
LPHD class
Attribute
Name
Attr.
Type
Explanation M/O Notes
LPHD Physical device information M
Data
Common Logical Node Information
PhyNam DPL Physical device name plate M
PhyHealth HealthENS Physical device health M
Proxy SPS Indicates if this LN is a proxy M
LLN0 class
Attribute
Name
Attr.
Type
Explanation M/O notes
LLN0 Logical node zero
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL_1 Name plate M
Loc SPS Local control behaviour O
OpTmh INS Operation time O
GoCB (ACSI class GOOSE control block)
GoCB GoCB
