CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-67
2.1.2.1 GoCB (GOOSE control block class definition)
2.1.3 LGOS (GOOSE subscription)
For firmware version 7.00 or higher, this LN Logical is used for monitoring GOOSE messages, diagnosing the subscription
state of a GOOSE message and has 24 instances inside the device
2.2 Logical Nodes for protection functions. LN Group:P
2.2.1 PIOC (Instantaneous overcurrent)
2.2.1.1 phsPIOC
This logical node class is used for phase instantaneous overcurrent and has 6 instances inside the device.
GoCB class
Attribute Name Attribute Type FC notes
GoEna BOOLEAN GO Enable (TRUE), disable (FALSE)
GoID VISIBLE STRING65 GO
DatSet Object Reference GO
ConfRev INT32U GO
NdsCom BOOLEAN GO
DstAddress PHYCOMADDR GO
LLN0 class
Attribute
Name
Attr.
Type
Explanation M/O notes
LLN0 Logical node zero
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
St SPS Status of the subscription M
LastStNum INS Last state number received O
ConfRevNum INS Expected conf. revision num. O
GoCBRef ORG Ref. to the subscribed GOOSE control block O
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str PhsACD Start O IOC PKP
Op PhsACT Operate M IOC OP
Blk SPS Block O
Settings
PIOCEna SPG Function O
InMagTyp ING_0 Input O
StrVal FloatASG Pickup level O
