7-68 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.1.2 phsPIOC_2
This logical node class is used for phase instantaneous overcurrent when setting group option is enabled and has 2
instances inside the device. This logical node class is available only for firmware version below 7.50.
2.2.1.3 ndPIOC
This logical node class is used for neutral instantaneous overcurrent and has 3 instances inside the device.
OpDlTmms ING_8 Trip delay O
RsDlTmms ING_8 Reset delay O
SnpshtEvEna SPG Snapshot events enabled O
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str PhsACD Start O IOC PKP
Op PhsACT Operate M IOC OP
Blk SPS Block O
Settings
PIOCEna SPG_2 Function O
InMagTyp ING_0_2 Input O
StrVal FloatASG_2 Pickup level O
OpDlTmms ING_8_2 Trip delay O
RsDlTmms ING_8_2 Reset delay O
SnpshtEvEna SPG_2 Snapshot events enabled O
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str NeutACD Start O IOC PKP
Op NeutACT Operate M IOC OP
Blk SPS Block O
Settings
PIOCEna SPG Function O
StrVal FloatASG Pickup level O
OpDlTmms ING_8 Trip delay O
RsDlTmms ING_8 Reset delay O
SnpshtEvEna SPG Snapshot events enabled O
