CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-69
2.2.1.4 ndPIOC_2
This logical node class is used for neutral instantaneous overcurrent if setting group option is enable and has 1 instance
inside the device. This logical node class is available only for firmware version below 7.50
2.2.1.5 gndPIOC/hsePIOC
This logical node class is used for ground instantaneous and sensitive ground instantaneous overcurrent. There are 6
instances (3 for ground and 3 for sensitive ground instantaneous overcurrent) of this logical node inside the device.
2.2.1.5 gndPIOC_2
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str NeutACD Start O IOC PKP
Op NeutACT Operate M IOC OP
Blk SPS Block O
Settings
PIOCEna SPG_2 Function O
StrVal FloatASG_2 Pickup level O
OpDlTmms ING_8_2 Trip delay O
RsDlTmms ING_8_2 Reset delay O
SnpshtEvEna SPG_2 Snapshot events enabled O
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str geNeutACD Start O IOC PKP
Op geNeutACT Operate M IOC OP
Blk geSPS Block O
Settings
PIOCEna geSPG Function O
InMagTyp geING_0 Input O
StrVal geFloatASG Pickup level O
OpDlTmms geING_8 Trip delay O
RsDlTmms geING_8 Reset delay O
SnpshtEvEna geSPG Snapshot events enabled O
