7-70 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
This logical node class is used for ground instantaneous and sensitive ground instantaneous overcurrent when setting
group option is enable. There are 2 instances (1 for ground and 1 for sensitive ground instantaneous overcurrent) of this
logical node inside the device. This logical node class is available only for firmware version below 7.50.
2.2.1.6 IsoGndPIOC
This logical node class is used for isolated ground overcurrent and has 3 instances inside the device.
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O IOC PKP
Op gePhsACT Operate M IOC OP
Blk geSPS Block O
Settings
PIOCEna geSPG_2 Function O
InMagTyp geING_0_2 Input O
StrVal geFloatASG_2 Pickup level O
OpDlTmms geING_8_2 Trip delay O
RsDlTmms geING_8_2 Reset delay O
SnpshtEvEna geSPG_2 Snapshot events enabled O
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O IOC PKP
Op gePhsACT Operate M IOC OP
Blk geSPS Block O
Settings
PIOCEna geSPG_2 Function O
VhStr geIntASG_2 Vh level O
VlStr geIntASG_2 Vl level O
IhStr geFloatASG_1_2 Ih level O
IlStr geFloatASG_1_2 Il level O
OpDlTmms geING_8_2 Trip delay O
RsDlTmms geING_8_2 Reset delay O
SnpshtEvEna geSPG_2 Snapshot events enabled O
