2.2.1.7 BknCndPIOC
This logical node class is used for broken conductor function and has 3 instances inside the device. This node have been
included for firmware versions 7.50 or above.
PIOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Instantaneous overcurrent
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O IOC PKP
Op gePhsACT Operate M IOC OP
Blk geSPS Block O
Settings
PIOCEna geSPG_2 Function O
StrVal geFloatASG_2 Pickup level O
OpDlTmms geING_8_2 Trip delay O
BlkCurrent geFloatASG_1_2 Operation Threshold O
SnpshtEvEna geSPG_2 Snapshot events enabled O
