7-72 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.2.2 PTOC (Time overcurrent)
2.2.2.1 phsPTOC
This logical node class is used for phase time overcurrent and has 6 instances inside the device.
2.2.2.2 phsPTOC_2
This logical node class is used for phase time overcurrent when setting group option is enabled and has 2 instances inside
the device. This logical node class is available only for firmware version below 7.50
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOC Time overcurrent
Data
Common Logical Node Information
Mod ModENC Mode M
Beh BehENS Behaviour M
Health HealthENS Health M
NamPlt LPL Name plate M
Status Information
Str gePhsACD Start O TOC PKP
Op gePhsACT Operate M TOC OP
Blk geSPS Block O TOC BLK
Settings
PTOCEna geSPG Function O
InMagTyp geING_0 Input O
StrVal geFloatASG Pickup level O
TmACrv geCURVE Curve O
VolRst geSPG Voltage Restraint O
TmMult geFloatASG TD Multiplier O
RsMod geING_0 Reset O
SnpshtEvEna geSPG Snapshot events enabled O
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOC Time overcurrent
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start O TOC PKP
Op gePhsACT Operate M TOC OP
Blk geSPS Block O TOC BLK
Settings
PTOCEna geSPG_2 Function O
InMagTyp geING_0_2 Input O
StrVal geFloatASG_2 Pickup level O
TmACrv geCURVE_3 Curve O
VolRst geSPG_2 Voltage Restraint O
TmMult geFloatASG_2 TD Multiplier O
RsMod geING_0_2 Reset O
SnpshtEvEna geSPG_2 Snapshot events enabled O
