CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-73
2.2.2.3 ndPTOC
This logical node class is used for neutral time overcurrent and has 3 instances inside the device.
2.2.2.4 ndPTOC_2
This logical node class is used for neutral time overcurrent when setting group option is enable and has 1 instances inside
the device.
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PIOC Time overcurrent
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str geNeutACD Start O TOC PKP
Op geNeutACT Operate M TOC OP
Blk geSPS Block O TOC BLK
Settings
PTOCEna geSPG Function O
StrVal geFloatASG Pickup level O
TmACrv geCURVE Curve O
TmMult geFloatASG TD Multiplier O
RsMod geING_0 Reset O
SnpshtEvEna geSPG Snapshot events enabled O
PTOC class
Attribute
Name
Attr.
Type
Explanation M/O notes
PTOC Time overcurrent
Data
Common Logical Node Information
Mod geModENC Mode M
Beh geBehENS Behaviour M
Health geHealthENS Health M
NamPlt geLPL Name plate M
Status Information
Str geNeutACD Start O TOC PKP
Op geNeutACT Operate M TOC OP
Blk geSPS Block O TOC BLK
Settings
PTOCEna geSPG_2 Function O
StrVal geFloatASG_2 Pickup level O
TmACrv geCURVE_3 Curve O
TmMult geFloatASG_2 TD Multiplier O
RsMod geING_0_2 Reset O
SnpshtEvEna geSPG_2 Snapshot events enabled O
