A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
IEC61850 Internal States ICD STATUS
UNKNOWN: when the relay has not the IEC61850
pr
otocol in the relay model the ICD status is unknow to
the unit
ICD ERROR: There is an error in the ICD file and the
re
lay ICD is not operative. To solve this issue it is
necessary to send a correct ICD to the relay using the
IEC61850 configurator tool. When the ICD error is raised
the IEC 61850 will not be operative (the IEC 61850
client, reports and gooses will not work). It is advisable to
include the ICD ERROR in the main error signal
configured for specific applications.
MODIFIED: The settings have been changed in the icd
but th
ey are still not written in the icd file in the relay
IN PROGRESS: The icd setting are being written to the
file in the relay
OK WITHOUT DAIS: The relay has not got the "Use DOI
&DAI" setting enab
led (true) and it is working properly
with the ICD file.
OK: The relay has got the "Use DOI &DAI" setting
enabled (
true) and it is working properly with the ICD file.
When that setting is set to true the icd setting prevails
over the relay settings.
OTHER INTERNAL STATES (NON CRITICAL)
Other internal states
USER MAP STATUS User map status: (0) Not configured ; (1) Configured
FACTORY CALIBRATION Calibration status (0) Relay calibrated; (1) Not calibrated
FLEXCURVE A STATUS User curve A: (0) Not configured (1) Configured
FLEXCURVE B STATUS User curve B: (0) Not configured (1) Configured
FLEXCURVE C STATUS User curve C: (0) Not configured (1) Configured
FLEXCURVE D STATUS User curve D: (0) Not configured (1) Configured
Green Zone Memory internal status
Yellow Zone Memory internal status
Orange Zone Memory internal status
Red Zone Memory internal status
UpTime System Time
Autocheck Internal States (Not available)
TIMER STATUS Real time clock autocheck (not available)
GRAPHIC STATUS Graphic display status (not available)
ALARM TEXT ARRAY
Text display status (not available)
OPERANDS - F650 - MODEL FX - GX
Internal System Status
