1-12 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
1.2 OVERVIEW CHAPTER 1: GETTING STARTED
Available Options are:
Table 1-2: REAR ETHERNET COMMUNICATIONS BOARD 2
For options C and D you must select the active physical media, by means of an internal selector inside the module. The
factory configuration for this selection is the 10/100BaseTX port. For firmware versions 7.00 and above, the following
options are available:
Finally, internal communication with input and output modules is performed via an internal CAN Bus, independent of the
one used for remote CAN Bus I/Os. This provides increased communication speed, and acknowledgement of modules,
abnormalities, etc. As this is a serial port supporting a communications protocol, it provides immunity against external or
internal disturbances.
Board Code Functionality
B One 10/100BaseTX port (self-negotiable speed)
C One 10/100BaseTX port and one 100BaseFX port.
D One 10/100BaseTX port and redundant 100BaseFX ports
E Redundant 10/100BaseTX ports
G 1588, 10/100 Base TX* + 100 Base TX
H 1588, 10/100 Base TX* + 100 Base FX
J PRP, 1588, 10/100 Base TX* + Redundant 100 Base FX
K PRP, HSR, RSTP, 1588, 10/100 Base TX* + Redundant 100 Base FX
L PRP, 1588, 10/100 Base TX + Redundant 100 Base TX
M PRP, HSR, RSTP, 1588, 10/100 Base TX + Redundant 100 Base TX
