CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-13
1.2 ACSI BASIC conformance statement
1.3 ACSI MODELS conformance statement
Client/ subscriber Server/
publisher
Value/ comments
Client-server roles
B11 Server side (of TWO-PARTY APPLICATION-ASSOCIATION) - Y
B12 Client
side of (TWO-PARTY APPLICATION-ASSOCIATION) - N
SCSMs supported
B21 SCSM: IEC 6185-8-1 used - Y
B22 SCSM: IEC 6185-9-1 used - N
B23 SCSM: IEC 6185-9-1 used - N
B24 SCSM: other - N
Generic substation event model (GSE)
B31 Publisher side - Y Both GSSE and
GOOSE
B32 Subscriber si
de Y - Both GSSE and
GOOSE
Transmission of sampled value model (SVC)
B41 Publisher side - N
B42 Subscriber si
de N -
Client/ subscriber Server/
publisher
Value/ comments
If Server side (B11) supported
M1 Logical device - Y
M2 Logical node - Y
M3 Data - Y
M4 Data set - Y
M5 Substitution - N
M6 Setting group control - Y
Reporting
M7 Buffered report control - Y
M7-1 sequence-number - Y
M7-2 report-time-stamp - Y
M7-3 reason-for-inclusion - Y
M7-4 data-set-name - Y
M7-5 data-reference - Y
M7-6 buffer-overflow - Y
M7-7 entryID - Y
M7-8 BufTm - Y
M7-9 IntgPd - Y
M7-10 GI - Y
M8 Unbuffered report control - Y
M8-1 sequence-number - Y
M8-2 report-time-stamp - Y
M8-3 reason-for-inclusion - Y
M8-4 data-set-name - Y
M8-5 data-reference - Y
M8-6 BufTm - Y
If Server side (B11) supported(cont.)
