7-50 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
Note: ACT includes origin attribute in ST, this is implemented according to Tissue 68.
2.3 Logical Nodes for protection related functions. LN Group: R
2.3.1 RDIR (Directional element)
2.3.1.1 phsRDIR
This logical node class is used for phase directional elements and has 3 instances inside the device.
PTUF class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
PTUF UnderFrequency
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Status Information
Str ACD Start M TUF PKP
Op ACD Operate M
TUF OP
Blk ACT Block E TUF BLK
Settings
StrVal ASG Start value (frequency) O Pickup Level (20-65)
BlkVal ASG Voltage Block Value O Minimun Voltage (10-300)
OpDlTmms ING Operate Delay Time O Trip Delay (0-900000)
Units in miliseconds
RsDlTmms ING Reset Delay Time O Reset Delay (0-900000)
Units in miliseconds
PTUFEna SPG Function TUF enable E Function (Enable,Disable)
RDIR class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
RDIR Directional Element
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Status Information
Dir ACD Direction M
Fixed to unknown value
Op ACT Operate O Phase Dir OP
Blk ACT Block O Phase Dir Block
BlkIn ACT Phase Dir Blk Inp O Phase Dir Blk Inp
Settings
ChrAng ASG Characteristic Angle O (-90, 90) MTA
BlkValV ASG Minimun operating current O
(0, 300) Pol V Threshold
PolOpMod ING Direction E (Reverse, Forward)
BlkMod ING Block Logical E (Prmission, Blocked)
RDIREna SPG Function Permission E (Enable, Disable)
