7-56 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
2.5.1.3 eveGGIO
This logical node class is used to map data from the list of any all internal digital states (PLC control events).
2.5.1.4 geRemoteInputsGGIO
This logical node class is used to map data from incoming GOOSE messages.
GGIO class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Status information
Ind1 SPS Ge n e ral I nd ica t i o n ( b i nary
input )
O Control Event 1
Ind2 SPS Ge n e ral I nd ica t i o n ( b i nary
input )
O Control Event 2
......... .......... ............... .......... ..............
Ind128 SPS Ge nera l Ind i cat i o n ( b i n a ry
input )
O Control Event 128
Ind129 SPS Ge nera l Ind i cat i o n ( b i n a ry
input )
O Switchgear 1 event 1
Ind130 SPS Ge nera l Ind i cat i o n ( b i n a ry
input )
O Switchgear 1 event 2
Ind131 SPS Ge nera l Ind i cat i o n ( b i n a ry
input )
O Switchgear 1 event 3
Ind132 SPS Ge nera l Ind i cat i o n ( b i n a ry
input )
O Switchgear 1 event 4
Ind133 SPS Ge nera l Ind i cat i o n ( b i n a ry
input )
O Switchgear 2 event 1
......... .......... ............... .......... ..............
Ind192 SPS Ge nera l Ind i cat i o n ( b i n a ry
input )
O Switchgear 16 event 4
GGIO class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
GGIO Generic process I/O
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Status information
Ind1 SPS General Indication ( binary
input )
O Remote Digital Input 1
Ind2 SPS General Indication ( binary
input )
O Remote Digital Input 2
......... .......... ............... .......... ..............
