GE Multilin F650 - Page 465

CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-59
2.6.3 MSQI (Sequence and imbalance)
Condition C: At least one of either data shall be used.
2.7 Logical Nodes for switchgear. LN Group: X
2.7.1 XCBR (Circuit Breaker)
Note: actVal in BCR is imlemented as INT32.
MSQI class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
MSQI Sequence and imbalance
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Measured values
SeqA SEQ Positive, Negative and Zero Sequence
Cu
rrent
C
SeqV SEQ Positive, Negative and Zero Sequence
V
oltage
C
XCBR class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
XCBR Circuit breaker
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M Number of Switchgear
Loc SPS Local operation M Local / Remote
OpCnt INS Operation counter M Breaker openings
Controls
Pos geDPC Switch position M Breaker open, close, und
BlkOpn SPC Block opening M Status-only
BlkCls SPC Block closing M Status-only
Metered Values
SumSwARs BCR Sum of Switched Amperes O Maximum KI2t value of any of
the p
hases
Status information
CBOpCap INS Circuit breaker operating capability M Fixed value = 5
Settings
ThAlSwA ASG Threshold Alarm of Switched Amps E Maximum KI2t
SumSwATmms ASG Sum of sw. Amps integration time E KI2t Integ. Time
ExNumTr ASG Excessive number of trips E Maximum Openings
ExNumTr1hr ASG Excessive number of trips in 1 hour E Max. Openings 1 hour
