7-62 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
3.2 setCharact_2
Enum type : setCharact(cont.)
Value Description supported new enum
value added
650 setting
internal
value
650 Relay curve
31 Definable curve 15 based on formula
[x=f(y,
A,B,C,D,E,F)]
N - - -
32 Definable curve 16 based on formula
[x=f(y,
A,B,C,D,E,F)]
N - - -
33 Vendor specific curve 1 defined by n
pair
s (x,y)
Y - 11 User Curve A
34 Vendor specific curve 2 defined by n
pair
s (x,y)
Y - 12 User Curve B
35 Vendor specific curve 3 defined by n
pair
s (x,y)
Y - 13 User Curve C
36 Vendor specific curve 4 defined by n
pair
s (x,y)
Y - 14 User Curve D
37 Vendor specific curve 5 defined by n
pair
s (x,y)
N - - -
38 Vendor specific curve 6 defined by n
pair
s (x,y)
N - - -
39 Vendor specific curve 7 defined by n
pair
s (x,y)
N - - -
40 Vendor specific curve 8 defined by n
pair
s (x,y)
N - - -
41 Vendor specific curve 9 defined by n
pair
s (x,y)
N - - -
42 Vendor specific curve 10 defined by n
pair
s (x,y)
N - - -
43 Vendor specific curve 11 defined by n
pair
s (x,y)
N - - -
44 Vendor specific curve 12 defined by n
pair
s (x,y)
N - - -
45 Vendor specific curve 13 defined by n
pair
s (x,y)
N - - -
46 Vendor specific curve 14 defined by n
pair
s (x,y)
N - - -
47 Vendor specific curve 15 defined by n
pair
s (x,y)
N - - -
48 Vendor specific curve 16 defined by n
pair
s (x,y)
N - - -
Enum type : setCharact_2
Value Description supported new enum
value added
650 setting
internal
value
650 Relay curve
0 Definite Time Y Y 0 Definite Time
1 Inverse Time Y Y 1 Definite Time
