CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-107
3.1.4 Protection activation information (ACT)
configuration, description and extension
d Vstring255 DC
O
geSwTypENS (SwTyp)
Attribute
Name
Attribute Type FC TrgOp Value/Value Range
M/O/C
DataAttribute
status
stVal Enumerated ST dchg Load Break,Disconnector,… M
q BVstring13 ST qchg M
t Utctime ST M
configuration, description and extension
d Vstring255 DC O
ACT class (Protection activation information)
gePhsACT
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST dchg M
phsA Boolean ST dchg O
phsB Boolean ST dchg O
phsC Boolean ST dchg O
q Bvstring13 ST qchg M
t Utctime ST M
originSrc Struct ST O
configuration, description and extension
d Vstring255 DC O
gePhsACT_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST dchg M
phsA Boolean ST dchg O
phsB Boolean ST dchg O
phsC Boolean ST dchg O
q Bvstring13 ST qchg M
t Utctime ST M
originSrc Struct ST O
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX AC_DLN_M
geNeutACT
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
general Boolean ST dchg M
neut Boolean ST dchg O
q Bvstring13 ST qchg M
t Utctime ST M
