CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-113
geFloatMV_2
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
mag
f
FloatAnalogueValue MX dchg M
FLOAT32 GC_1
q BVstring13 MX qchg M
t Utctime MX M
Configuration, description and extension
units
SIUnit
Multiplier
Unit CF O
ENUMERATED(Byte) M
ENUMERATED(Byte) O
d Vstring255 DC O
dataNs Vstring255 EX AC_DLN_M
geFloatMV_3
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
mag
f
FloatAnalogueValue MX dchg M
FLOAT32 GC_1
q BVstring13 MX qchg M
t Utctime MX M
Configuration, description and extension
units
SIUnit
Multiplier
Unit CF O
ENUMERATED(Byte) M
ENUMERATED(Byte) O
d Vstring255 DC O
geIntMV
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
instMag
i
IntAnalogueValue MX
------
O
INT32 GC_1
mag
i
IntAnalogueValue MX dchg M
INT32 GC_1
q BVstring13 MX qchg M
t Utctime MX M
Configuration, description and extension
units
SIUnit
Multiplier
Unit CF O
ENUMERATED(Byte) M
ENUMERATED(Byte) O
db INT32U CF O
d Vstring255 DC O
geIntMV_1
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
instMag
i
IntAnalogueValue MX
------
O
INT32 GC_1
