CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-115
units
SIUnit
Multiplier
Unit CF O
Byte M
Byte O
db INT32U CF O
dbAng INT32U CF O
zeroDb INT32U CF O
rangeC RangeConfig CF O
rangeAngC RangeConfig CF O
d Vstring255 DC O
geFloatCMV_1
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
measured attributes
instCVal
mag
f
FloatVector MX
------
O
FloatAnalogueValue
FLOAT32
cVal
mag
f
FloatVector MX dchg M
FloatAnalogueValue
FLOAT32
range ENUMERATED(Byte) MX dchg O
rangeAng ENUMERATED(Byte) MX dchg O
q BVstring13 MX qchg M
t Utctime MX M
configuration, description and extension
units
SIUnit
Multiplier
Unit CF O
Byte M
Byte O
db INT32U CF O
dbAng INT32U CF O
zeroDb INT32U CF O
rangeC RangeConfig CF O
rangeAngC RangeConfig CF O
d Vstring255 DC O
dataNs Vstring255 EX M
