CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-121
3.4.3 Enumerated status setting (ENG)
3.4.4 Object reference setting
3.5 Common data class specifications for analogue settings
3.5.1 Analoque setting (ASG)
ENG class
geENG
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setVal Enumerated SP PolQty AC_NSG_M
configuration, description and extension
d Vstring255 DC O
geENG_2
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setVal Enumerated SG PolQty AC_SG_M
configuration, description and extension
d Vstring255 DC O
ORG class
geORG
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setSrcRef ObjectReference SP Object reference M
configuration, description and extension
d Vstring255 DC O
ASG class
geIntASG
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setMag
i
IntAnalogueValue SP AC_NSG_M
INT32 GC_1
configuration, description and extension
units Unit CF
minVal
i
IntAnalogueValue CF O
INT32 GC_1
