GE Multilin F650 - Page 573

CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-167
3.4 Common data class specifications for status settings
3.4.1 Single point setting (SPG)
3.4.2 Integer status setting (ING)
stVal Enum ST dcgh M
q BVstring13 ST qchg M
t Utctime ST M
configuration, description and extension
ctlModel ENUMERATED CF M
d Vstring255 DC O
SPG class
geSPG
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setVal Boolean SP AC_NSG_M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX O
geSPG_2
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setVal Boolean SG AC_SG_M
configuration, description and extension
d Vstring255 DC O
dataNs Vstring255 EX O
ING class
geING_0
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setVal Boolean SP AC_NSG_M
configuration, description and extension
minVal INT32 CF O
maxVal INT32 CF O
stepSize INT32 CF O
d Vstring255 DC O
dataNs Vstring255 EX O
geING_0_2
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
setting
setVal Boolean SG AC_SG_M
configuration, description and extension
