7-200 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
12 PIXIT for File transfer model
13 PIXIT for Service tracking model
Is the timestamp of a binary event adjusted to the configured
scan cycle
Deprecated
Does the device support time zone and daylight saving Y
Which attributes of the SNTP response packet are validated Y Leap indicator not equal to 3
Y Mode is equal to SERVER
N OriginateTimestamp is equal to value
sent by the SNTP client as Transmit
Timestamp
Y RX/TX timestamp fields are checked for
reasonableness
Y SNTP version 3 and/or 4
N other (describe)
Do the COMTRADE files have local time or UTC time and is this
configurable
Local
N
<additional items>
Description Value / Clarification
What is structure of files and directories
Where are the COMTRADE files stored
Are comtrade files zipped and what files are included in each zip
file
/COMTRADE
N
Directory names are separated from the file name by ā/ā
The maximum file name size including path (recommended 64
chars)
255 chars
Are directory/file name case sensitive Case sensitive
Maximum file size for SetFile
Is the requested file path included in the MMS fileDirectory
respond file name
Y
Is the wild char supported MMS fileDirectory request No
Is it allowed that 2 clients get a file at the same time Y same file
Y different files
Which files can be deleted
Description Value / Clarification
Which ACSI services are tracked by LTRK.GenTrk Not Applicable
