7-242 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.3 IEC 61850 CONFIGURATOR CHAPTER 7: IEC 61850 PROTOCOL
Fixed GOOSE is recommended for implementations requiring GOOSE data transfer between F650 relay and UR series IEDs.
Fixed GOOSE is not supported for firmware version 7.00 or higher.
Configurable GOOSE is recommended for implementations that require GOOSE data transfer between F650 relays and
devices from other manufacturers.
USING "IEC 61850 CONFIGURATOR" FOR GOOSE SETUP
The F650 relay allows a maximum of transmission/reception GOOSES as it is described below:
• For firmware version below 7.00, a maximum of four transmission GOOSE applications and a maximum of 16
reception GOOSE applications. Maximum one of the transmission GOOSEs can be Fixed GOOSE and maximum one of
the reception GOOSEs can be Fixed GOOSE. Fixed GOOSE can be used at the same time as configurable GOOSE.
• For firmware version 7.00 or higher a maximum of four transmission and 24 reception GOOSE applications are
suppor
ted. No fixed GOOSEs are supported for firmware version 7.00 or higher.
In F650, Data Sets for configurable GOOSES, both for reception and transmission, have limited number of elements:
• For firmware version below 7.20, Data Sets for configurable GOOSES, in transmission and reception GOOSES, can have
a maximum of 64 elements.
• For firmware version 7.20 or higher, Data Sets for reception G
OOSES can have a maximum of 64 elements and Data
Sets for transmissions GOOSES can have a maximum of 128 elements.
The elements of Data Sets for transmission GOOSEs can only be leaf elements (Data Attributes), and cannot be complex
structures (Data Objects). For firmware version 7.00 or higher Data Sets for transmission GOOSEs can be Data Attributes or
Data Objects.
The elements of Data Sets for reception GOOSEs can be of any types supported in IEC 61850 standard and can be both
leaf elements (Data Attributes) and compelx structures (Data Objects). However F650 relay can map to its internal
variables incoming data of type Boolean, Float, Integer and any of the bits from Bitstring data type.
Configuration of the transmission part of GOOSE
GOOSE Transmission tab contains four different panels:
• GOOSE TX Main:Lists all GOOSE control blocks present in the device
• DataSet Sources:Enables the user to browse through complet
e data model, select data attributes and drag them to
the DataSet (DataSet panel on the right)
• GOOSE TX Properties:Shows parameters of selected GOOSE control block and VLAN settings
• DataSet:Shows the name of the GOOSE D
ataSet and list all of its members
