10-16 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
10.13 DIRECTIONAL ELEMENTS (67P, 67N, 67G, 67SG) CHAPTER 10: COMMISSIONING
Configure one of the outputs to be activated only by unit 50SG.
Apply the following tests:
Pol V Threshold 10 V
Elements Phase under test Polarization Phase Element trip
Channel Magnitude Channel Magnitude
Mod Arg Mod Arg
50SG/67SG ISG 2 A 0º VI 60 V 0º NO
60 V 180º YES
VII 0 V 0º
VIII 0 V 0º
