11-2 F650 DIGITAL BAY CONTROLLER GEK-106310-AF

11.1 EXAMPLE 1: COMMUNICATION & PROTECTION SETTINGS CHAPTER 11: APPLICATION EXAMPLES

Click ON key.

Ethernet LAN (10/100 Base T rear port of the relay)

In the Laptop choose My PC-Control Panel-Network-Protocols-Protocol TCP/IP-Advance and set in IP Address screen

the following:

IP Address 192.168.37.126

Netmask 255.255.255.0

In the front of F650 go to the Main Settings screen.

choose Change Settings .

Choose Comm Settings and press down the rotating knob or down key.

Choose Network 0 . It is displayed IP Address OCT 1 and set it according to the following table:

Go to General Settings . General Settings 0 is now displayed.

Set ModBus Port Number to 502 .

Set ModBus Address COM1 to 254 .

Move clockwise the rotating knob or press the down key to find Press Enter to End and press it down to validate the

setting.

Connect a crossover 10/100 MB Ethernet cable from PC to the relay.

Open the EnerVista 650 SETUP program in the PC and under Communication  Computer menu and set:

IP Address 192.168.37.125

Port 502

Unit Identifier 254

Control Type to ModBus/TCP

Startup Mode to Communicate with relay

Click ON key.

The program starts connection with the relay showing the progress screen.

Sequence

Action Setting Action

---- IP Address OCT 1 Set to 192

Move rotating knob clockwise IP Address OCT 2 Set to 168

Move rotating knob clockwise IP Address OCT 3 Set to 37

Move rotating knob clockwise IP Address OCT 4 Set to 125

Move rotating knob clockwise Netmask OCT 2 Set to 255

Move rotating knob clockwise Netmask OCT 3 Set to 255

Move rotating knob clockwise Netmask OCT 4 Set to 0

Move rotating knob clockwise Netway IP OCT 1 Leave default setting without any change

Move rotating knob clockwise Netway IP OCT 2 Leave default setting without any change

Move rotating knob clockwise Netway IP OCT 3 Leave default setting without any change

Move rotating knob clockwise Netway IP OCT 4 Leave default setting without any change

Move rotating knob clockwise Press INTRO Press enter to validate settings
