CHAPTER 11: APPLICATION EXAMPLES 11.3 EXAMPLE 3: SET AN OPERATION
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 11-9
Under
SETPOINT RELAY CONFIGURATION OPERATIONS
Select Operation 0
Command Text Close C_Output_00_00
Interlock Type None
Interlocks ---
Final State Type None
Final States ---
Frontal Key F2
Contact Input None
Virtual Output None
Time Out 500 (default)
MMI ---
Com1 ---
Com 2 ---
ETH-Master 1 ---
ETH Master 2 ---
ETH Master 3 ---
ETH Mastef 4 ---
In the same window (next rows)
Select Operation 1
Command Text Reset C_Output_00_00
Interlock Type None
Interlocks ---
Final State Type None
Final States ---
Frontal Key F1
Contact Input None
Virtual Output None
Time Out 500 (default)
MMI ---
Com1 ---
Com 2 ---
ETH-Master 1 ---
ETH Master 2 ---
ETH Master 3 ---
ETH Mastef 4 ---
