A-4 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
Control Event Bits (128 elements)
CONTROL EVENT 1 Control Event 1 Activation Bit
CONTROL EVENT 2 Control Event 2 Activation Bit
... ...
CONTROL EVENT 128 Control Event 128 Activation Bit
Latched Virtual Inputs (32 elements)
LATCHED VIRT IP 1 Latched virtual input 1
LATCHED VIRT IP 2 Latched virtual input 2
... ...
LATCHED VIRT IP 32 Latched virtual input 32
Self Reset Virtual Inputs (32 elements)
SELF-RST VIRT IP 1 Self reset virtual input 1
SELF-RST VIRT IP 2 Self reset virtual input 2
... ...
SELF-RST VIRT IP 32 Self reset virtual input 32
Contact Inputs Type 1Board
CONT IP_X_CC1 Input 1 (CC1) in Board X
CONT IP_X_CC2 Input 2 (CC2) in Board X
... ...
CONT IP_X_CC16 Input 16 (CC16) in Board X
Contact Inputs Type 2 Board
CONT IP_X_CC1 Input 1 (CC1) in Board X
CONT IP_X_CC2 Input 2 (CC2) in Board X
... ...
CONT IP_X_CC8 Input 8 (CC8) in Board X
CONT IP_X_CC9
(V
a_COIL1)
Contact Input 09 (Va_COIL1) for slot X. Input voltage (Va)
detected, Circuit 1. Complete circuit supervised
CONT IP_X_CC10
(V
b_COIL1)
Contact Input 10 (Vb_COIL1) for slot X. Input voltage (Vb)
detected, Circuit 1. Complete circuit supervised
CONT IP_X_CC11
(V
a_COIL2)
Contact Input 11 (Va_COIL2) for slot X. Input voltage (Va)
detected, Circuit 1. Complete circuit supervised
CONT IP_X_CC12
(V
b_COIL2)
Contact Input 12 (Vb_COIL2) for slot X. Input voltage (Vb)
detected, Circuit 2. Complete circuit supervised
CONT IP_X_CC13
(O
7_SEAL)
Contact Input 13 (07_SEAL) for slot X. Current detected.
Con
tact output associated with current flow > 100 mA
latched
CONT IP_X_CC14
(O
8_SEAL)
Contact Input 14 (08_SEAL) for slot X. Current detected.
Con
tact output associated with current flow > 100 mA
latched
CONT IP_X_CC15
(S
UP_COIL1)
Contact Input 15 (SUP_COIL1) for slot X. Output for
circuit 1 supervision element
CONT IP_X_CC16
(S
UP_COIL2)
Contact Input 16 (SUP_COIL2) for slot X. Output for
circuit 2 supervision element
Contact Inputs Type 4 Board
CONT IP_X_CC1 Input 1 (CC1) in Board X
CONT IP_X_CC2 Input 2 (CC2) in Board X
... ...
CONT IP_X_CC32
Input 32 (CC32) in Board X
OPERANDS - F650 - MODEL FX - GX
Internal System Status
