A-14 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
A.1 OPERANDS - F650 - MODEL FX - GX APPENDIX A: LOGIC OPERANDS
Ground IOC
GROUND IOC1 BLOCK
Ground instantaneous overcurrent element block Group
1
GROUND IOC1 PKP
Ground instantaneous overcurrent element pickup
Gr
oup 1
GROUND IOC1 OP
Ground instantaneous overcurrent element operation
(trip) Gr
oup 1
GROUND IOC2 BLOCK
Ground instantaneous overcurrent element block Group
2
GROUND IOC2 PKP
Ground instantaneous overcurrent element pickup
Gr
oup 2
GROUND IOC2 OP
Ground instantaneous overcurrent element operation
(trip) Gr
oup 2
GROUND IOC3 BLOCK
Ground instantaneous overcurrent element block Group
3
GROUND IOC3 PKP
Ground instantaneous overcurrent element pickup
Gr
oup 3
GROUND IOC3 OP
Ground instantaneous overcurrent element operation
(trip) Gr
oup 3
Sensitive Ground IOC
SENS GND IOC1 BLK
Sensitive ground instantaneous overcurrent element
block Gr
oup 1
SENS GND IOC1 PKP
Sensitive ground instantaneous overcurrent element
pickup
Group 1
SENS GND IOC1 OP
Sensitive ground instantaneous overcurrent element
operation (trip) Gr
oup 1
SENS GND IOC2 BLK
Sensitive ground instantaneous overcurrent element
block Gr
oup 2
SENS GND IOC2 PKP
Sensitive ground instantaneous overcurrent element
pickup
Group 2
SENS GND IOC2 OP
Sensitive ground instantaneous overcurrent element
operation (trip) Gr
oup 2
SENS GND IOC3 BLK
Sensitive ground instantaneous overcurrent element
block Gr
oup 3
SENS GND IOC3 PKP
Sensitive ground instantaneous overcurrent element
pickup
Group 3
SENS GND IOC3 OP
Sensitive ground instantaneous overcurrent element
operation (trip) Gr
oup 3
Isolated Ground
ISOLATED GND1 BLK
Isolated ground instantaneous overcurrent element
block Gr
oup 1
ISOLATED GND1 PKP
Isolated ground instantaneous overcurrent element
pickup
Group 1
ISOLATED GND1 OP
Isolated ground instantaneous overcurrent element
operation (trip) Gr
oup 1
ISOLATED GND2 BLK
Isolated ground instantaneous overcurrent element
block Gr
oup 2
ISOLATED GND2 PKP
Isolated ground instantaneous overcurrent element
pickup
Group 2
ISOLATED GND2 OP
Isolated ground instantaneous overcurrent element
operation (trip) Gr
oup 2
ISOLATED GND3 BLK
Isolated ground instantaneous overcurrent element
block Gr
oup 3
ISOLATED GND3 PKP
Isolated ground instantaneous overcurrent element
pickup
Group 3
ISOLATED GND3 OP
Isolated ground instantaneous overcurrent element
operation (trip) Group 3
OPERANDS - F650 - MODEL FX - GX
Internal System Status
To Next Page
